Working area: 1600x2500mm
CNC or not: CNC
Delivery Time: 20-25 working Days
Certificatres: CE, FDA, ISO
Voltage: AC 220V/380V, 1P/3P, 50HZ/60HZ
Supply Ability: 90 Sets/Month
Packing size: 3600*2260*1320mm
Payment Terms: T/T(Telegraphic Transfer), Mastercard, e-Checking
1. Imported Taiwan square linear guide and servo motor ensure high accuracy, fast cutting speed and stable working performance;
2. Whole machine is welded with thick square seamless steel structure and treated with high temperature, ensures high accuracy, no
deformation and super long service life;
3. The whole piece aluminum platform is honeycomb structure, not easy to deform, sound-absorbing, etc.
4. Digital cutting machine was designed easy to install, set-up and operate;
5. Being equipped with infrared sensor and emergency stop devices, guarantees safety;
6. Cutting by knife not laser, no air pollution, no burnt edge, cutting speed is 5-8 times faster than laser cutting machine.
Ruida control system, stable and easy operate. Support multiple formats.
Oscillating Knife Cutting head, Suitable for a variety of materials.
9.0kw air vacuum pump, big adsorption power. Fix the materials stable.
Spindle head as option parts, the machine can add different head for different working materials.
Taiwan Delta servo motor and driver, enclosed system, high precision and fast speed cutting.
Auto feeding and unloading working table. The table can rotate to achieve the mass materials cutting automatic.
Vacuum table, the materials on the table will be fixed automatic.
4cm Aluminum alloy table. Very strong and durable.
# Working area:1600x2500x80mm
# Oscillating knife cutting head
# Rack and pinion transmission
# Taiwan HIWIN guide rails Y axis20mm X axis15mm
# Rudia control system, RDD6584g
# Taiwan Delta servo motor &driver
# Aviation aluminum vacuum adsorption table with felt
# 9.0kw air vacuum pump with silencer
# boke smart nest software
# red pointer
# 40mm Aluminum alloy vacuum table
# Cylinder for press materials
# 20 sets cutting tools
# Another head V-cut head
# Pneumatic head cutting head
# Another Round knife cutting head
# CCD camera
# Auto feeding system
|Max. working area||1600*2500mm|
|Max. moving speed||1200mm/s|
|Max. cutting speed||800mm/s(plesae set the speed according to the material)|
|Tools configuration||Various cutting tools, creasing wheel, pen, cross positioning laser|
|Applicable material||Corrugated paper, non woven fabric , PVC expansion sheet, KT board, foam board, grey paperboard, cardboard, vehicle sticker, adhesive sticker etc.|
|Cutting depth||Max 50mm|
|Mechanical precision||Maximum 0.05mm|
|Repeated positioning accuracy||±0.05mm|
|Driving system||Delta servo motor|
|Control system||Ruida control system|
|Material fixing method||High power vacuum absorption with felt|
|Support file||DXF, PLT, AI, SVG, PDF, NC, DST, DSB, etc.|
|Operating environment||Temperature 0-40℃, Humidity 20%-80%RH|
The cutting machine can cut many kinds of soft materials and some hard materials as well. Such as:
Cloth, fabric, mash, jean, fiber, many layers Leather, PVC, PU, cloth Cardboard, corrugated board, honeycomb board,
chipboard, plastic corrugated board Shoe insole, EVA,rubber, PE foam, Car mats,Composite materials, plastic, etc.
CNC HS code: 8465990000
Laser HS code: 8456110090
Oscillating knife cutting machine：8453800000
